PA UT (PAUT): Radius area of the complex shaped composites and other materials

ISONIC RADIUS-Scan software application was created for the inspection of the inner radius areas of various cornered parts made of composites, metals, etc using Linear Array Probes equipped with specially designed wedges contoured according to the inner corner / radius surface




PDF Brochure

This inspection software option is available for the ISONIC 3510T / ISONIC 3510, ISONIC 2010, and ISONIC 2009 UPA Scope instruments and featured with:
  • True-To-Geometry Weld Overlay Volume Corrected Imaging - Cross Sectional and Top (C-Scan)- / Side- / End- View and 3D
  • 0-Deg-Corner-Scan Cross Sectional Coverage
  • Intuitive Image Guided PA Pulser Receiver with Beam Forming View
  • DAC / TCG Normalization
  • Built-In Corner Shape Geometry Editor and Ray Tracer - Scanning Pattern Design
  • Independent on TCG Gain Per Focal Law Correction
  • Encoded and Time based C-Scan
  • 100% Raw Data Capturing
  • Automatic Defects Alarming Upon C-Scan Acquisition Completed a Automatic Creation of Editable Defects List
  • Comprehensive Postrpocessing Including: g Recovery and Evaluation of Captured A-Scans from the Recorded Cross Sectional Views (Sector Scan) and C-Scans
    • Recovery of Cross Sectional Views from the Recorded C-Scans
    • Converting Recorded C-Scans or their Segments into 3D Images
    • Off-Line Gain Manipulation
    • Off-Line DAC to TCG / TCG to DAC toggling for all types of stored files (A-Scans, cross-sectional veiwes, C-Scans, etc)
    • Off-Line DAC Normalization of the Recorded Images / DAC Evaluation
    • Off-Line editing of Gain per Shot Correction applied to the stored the Cross-sectional Views / C-Scan data
    • Numerous Filtering / Reject Options ( by Geometry / Position / By Amplitude / dB-to-DAC / etc)
    • Defects Sizing
    • Automatic Creation of Defect List and Storing it Into a Separate File g Automatic Creating of Scanning Integrity Report
    • Automatic creating of inspection reports - hard copy / PDF File
The movies below illustrate the inspection of the corner radius area in the bended carbon fiber (CFRP) profile and in the T-stringer with use of the ISONIC 3510 instrument





Initially developed for the inspection of the bended areas of the composite profiles the RADIUS-Scan inspection SW application is also suitable for the inspection of various metallic parts, for example, rotor shafts, castings, etc from the ID / bored surface. Use of VAUT (Video Aided Ultrasonic Testing) technology allows permanent visual monitoring of the bored / ID surface whilst scanning and recording of the video information along with the ultrasonic inspection data synchronously into the same inspection results fileThe movies below illustrate:

  • Distinguishing subsurface voids in the casted case of automotive engines before the machining



  • Checking the instrument's settings and operation on the performance demonstration block (PDB):



  • VAUT supported scanning of the hollow rotor shaft from the bored surface above the region of interest (ROI):



  • Postprocessing of the recorded data:



    • Note: In order to accelerate the data stream the video above is linked to the Youtube. In case the YouTube may not be accessed from your location please use the link below


    DOWNLOAD AND PLAYBACK THE EXEMPLARY INSTRUMENTS FILES

    The archive comprices some Exemplary Instrument Files for this application

    The files should be extracted from the archive and played in the regular PC running under Win'XP, 7, 8, 10, 11 with use of the freely distributable ISONIC PA Office software package
